DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Main Purpose | Outputs and Type | Voltage - Output | Current - Output | Voltage - Input | Regulator Topology | Frequency - Switching | Contents | Utilized IC / Part | Power - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TPS568215EVM-762EVAL BOARD FOR TPS568215 |
2 |
|
Datasheet | D-CAP3™, SWIFT™ | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.2V | 8A | 4.5V ~ 17V | Buck | 1.2MHz | Board(s) | TPS568215 |
|
TPS61096EVM-787EVAL BOARD FOR TPS61096A |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 18V | 30mA | 1.8V ~ 5.5V | Boost | - | Board(s) | TPS61096A |
|
TPS62135EVM-698EVAL BOARD FOR TPS62135 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 3.3V or 5V | 4A | 3V ~ 17V | Buck | 2.5MHz | Board(s) | TPS62135 |
|
TPS62410Q1-EVMEVAL BOARD FOR TPS62410Q1 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 2 Non-Isolated Outputs | - | 1.2V, 1.8V | 800mA, 800mA | 2.5V ~ 6V | Buck | 2.25MHz | Board(s) | TPS62410-Q1 |
|
TPS63027EVM-870EVAL BOARD FOR TPS63027 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Up or Down | 1 Non-Isolated Output | - | 3.3V | 2A | 2.3V ~ 5.5V | Buck-Boost | 2.5MHz | Board(s) | TPS63027 |
|
TPS61253AEVM-803EVAL BOARD FOR TPS61253A |
2 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 5V | 1.5A | 2.3V ~ 5.5V | Boost | 3.5MHz | Board(s) | TPS61253A |
|
TPS54308EVM-876EVAL BOARD FOR TPS54308 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 3.3V | 3A | 4.5V ~ 28V | Buck | 350kHz | Board(s) | TPS54308 |
|
TPS565201EVM-858EVAL BOARD FOR TPS565201 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.05V | 5A | 4.5V ~ 17V | Buck | 550kHz | Board(s) | TPS565201 |
|
TPS62821EVM-005EVAL BOARD FOR TPS62821 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.8V | 1A | 2.4V ~ 5.5V | Buck | - | Board(s) | TPS62821 |
|
TPS65130EVM-839EVAL BOARD FOR TPS65130 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Positive and Negative | 2 Non-Isolated Outputs | - | 8V, -5V | 250mA, 200mA | 2.7V ~ 5.5V | Boost | 1.38MHz | Board(s) | TPS65130 |
|
TPSM84209EVM-014EVAL BOARD FOR TPSM84209 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.2V ~ 6V | 2.5A | 4.5V ~ 28V | Buck | - | Board(s) | TPSM84209 |
|
LMZM23600EVMEVAL BOARD FOR LMZM23600 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 2.5V ~ 15V | 500mA | 4V ~ 36V | Buck | 800kHz | Board(s) | LMZM23600 |
|
LMZM23601EVMEVAL BOARD FOR LMZM23601 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 2.5V ~ 15V | 1A | 4V ~ 36V | Buck | 800kHz | Board(s) | LMZM23601 |
|
LMZM23601V3EVMEVAL BOARD FOR LMZM23601 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 3.3V | 1A | 4V ~ 36V | Buck | 750kHz | Board(s) | LMZM23601 |
|
TLV62569APEVM-860EVAL BOARD FOR TLV62569A |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.8V | 2A | 2.5V ~ 5.5V | Buck | 1.5MHz | Board(s) | TLV62569A |
|
TPS613221AEVM-019EVAL BOARD FOR TPS613221A |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 3.3V | - | 0.9V ~ 3.2V | Boost | - | Board(s) | TPS613221A |
|
TPS543C20EVM-054EVAL BOARD FOR TPS543C20 |
2 |
|
Datasheet | SWIFT™ | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 0.9V | 40A | 5V ~ 16V | Buck | 500kHz | Board(s) | TPS543C20 |
|
LMR14010AEVMEVAL BOARD FOR LMR14010A |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 5V | 1A | 6V ~ 18V | Buck | 700kHz | Board(s) | LMR14010A |
|
LMR36006BEVMEVAL BOARD FOR LMR36006B |
2 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 3.3V or 5V | 600mA | 4.2V ~ 60V | Buck | 1MHz | Board(s) | LMR36006B |
|
LMR36015AEVMEVAL BOARD FOR LMR36015Q1 |
2 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 3.3V or 5V | 1.5A | 4.2V ~ 60V | Buck | 400kHz | Board(s) | LMR36015-Q1 |
