Common Mode Chokes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SCR22-060-1R0A075JHCMC 7.5MH 6A 2LN TH |
49 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 7.5 mH @ 10 kHz | 6A | 42mOhm | 250V | 250V | -25°C ~ 120°C | - | - | - | - | - |
|
SCT19XV-190-1R5A005JHCMC 93UH 19A 2LN TH AEC-Q200 |
53 |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 93 µH @ 100 kHz | 19A | 1.95mOhm | 1000V (1kV) | 1000V (1kV) | -40°C ~ 150°C | AEC-Q200 | - | - | - | - |
|
SCR31HA-070-1R1A039JH-PCMC 3.85MH 7A 2LN TH |
72 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 3.85 mH @ 10 kHz | 7A | 24mOhm | 250V | 250V | 25°C ~ 120°C | - | - | - | - | - |
|
|
SCR31HA-045-0R8A080JH-PCMC 8.05MH 4.5A 2LN TH |
68 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 8.05 mH @ 10 kHz | 4.5A | 63.6mOhm | 250V | 250V | 25°C ~ 120°C | - | - | - | - | - |
|
SN16-300CMC 60UH 8A 2LN TH |
59 |
|
Datasheet | Vertical, No Base, 2 PC Pin | Power Line | 2 | - | 60 µH @ 100 kHz | 8A | 21mOhm | - | - | -25°C ~ 105°C | - | - | - | - | - |
|
SC-18-E12JCMC 1.2MH 18A 2LN TH |
45 |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 1.2 mH @ 10 kHz | 18A | 9mOhm | 250V | 250V | -40°C ~ 120°C | - | - | - | - | - |
|
SC-10-200CMC 2MH 10A 2LN TH |
86 |
|
Datasheet | Horizontal, No Base, 4 PC Pin | Power Line | 2 | - | 2 mH @ 100 kHz | 10A | 28mOhm | 250V | 250V | -40°C ~ 105°C | - | - | - | - | - |
|
SC-17-E27JHCMC 2.75MH 17A 2LN TH |
92 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 2.75 mH @ 100 kHz | 17A | - | 250V | 250V | -40°C ~ 120°C | - | - | - | - | - |
|
SC22-08-170CMC 1.7MH 8A 2LN TH |
100 |
|
Datasheet | Horizontal, No Base, 4 PC Pin | Power Line | 2 | - | 1.7 mH @ 10 kHz | 8A | 20mOhm | 250V | 250V | -40°C ~ 120°C | - | - | - | - | - |
|
|
SC-06-E70JKHCMC 7MH 6A 2LN TH |
89 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 7 mH @ 10 kHz | 6A | - | 250V | 250V | -40°C ~ 120°C | - | - | - | - | - |
|
SC-20-E18JCMC 1.8MH 20A 2LN TH |
38 |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 1.8 mH @ 10 kHz | 20A | 6.8mOhm | 250V | 250V | -40°C ~ 120°C | - | - | - | - | - |
|
SC22-08-260CMC 2.6MH 8A 2LN TH |
99 |
|
Datasheet | Horizontal, No Base, 4 PC Pin | Power Line | 2 | - | 2.6 mH @ 1 kHz | 8A | 30mOhm | 250V | 250V | -40°C ~ 120°C | - | - | - | - | - |
|
|
SC-15-35JHCMC 3.5MH 15A 2LN TH |
96 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 3.5 mH @ 1 kHz | 15A | - | 250V | 250V | -40°C ~ 105°C | - | - | - | - | - |
|
SC-18-180CMC 1.8MH 18A 2LN TH |
29 |
|
Datasheet | Horizontal, No Base, 4 PC Pin | Power Line | 2 | - | 1.8 mH @ 1 kHz | 18A | 11mOhm | 250V | 250V | -40°C ~ 105°C | - | - | - | - | - |
|
SC-08-1000CMC 10MH 8A 2LN TH |
50 |
|
Datasheet | Vertical, No Base, 4 PC Pin | Power Line | 2 | - | 10 mH @ 100 kHz | 8A | 70mOhm | 250V | 250V | -40°C ~ 105°C | - | - | - | - | - |
|
|
SC-18-E15JHCMC 1.5MH 18A 2LN TH |
52 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 1.5 mH @ 100 kHz | 18A | - | 250V | 250V | -40°C ~ 120°C | - | - | - | - | - |
|
|
SC-10-E80JHCMC 8MH 10A 2LN TH |
74 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 8 mH @ 10 kHz | 10A | - | 250V | 250V | -40°C ~ 120°C | - | - | - | - | - |
|
SC-05-100JVCMC 15MH 5A 2LN TH |
76 |
|
Datasheet | Vertical, 4 PC Pin | Power Line | 2 | - | 15 mH @ 16 kHz | 5A | - | 250V | 250V | -40°C ~ 105°C | - | - | - | - | - |
|
|
SC-18-15JHCMC 1.5MH 18A 2LN TH |
99 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 1.5 mH @ 100 kHz | 18A | - | 250V | 250V | -40°C ~ 105°C | - | - | - | - | - |
|
|
SC-10-55JHCMC 5.5MH 10A 2LN TH |
96 |
|
Datasheet | Horizontal, 4 PC Pin | Power Line | 2 | - | 5.5 mH @ 1 kHz | 10A | - | 250V | 250V | -40°C ~ 105°C | - | - | - | - | - |
