Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PEH227MKL3780QE4CAP ALUM 780UF 63V SOLDER LUG TH |
528 |
|
Datasheet | PEH227 | Bulk | Active | 780 µF | -10%, +30% | 63 V | 107mOhm @ 100Hz | 1500 Hrs @ 150°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 1.61 A @ 100 Hz | 4.784 A @ 100 kHz | - | 0.600" (15.24mm) | 0.638" Dia (16.20mm) | 1.130" (28.70mm) | - | Through Hole | |
|
TE1162-E3CAP ALUM 100UF 16V AXIAL TH |
420 |
|
Datasheet | TE | Bulk | Active | 100 µF | -10%, +75% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | - | 0.354" Dia x 0.807" L (9.00mm x 20.50mm) | - | - | Through Hole | |
|
TE1105-E3CAP ALUM 250UF 6V AXIAL TH |
296 |
|
Datasheet | TE | Bulk | Active | 250 µF | -10%, +75% | 6 V | - | 2000 Hrs @ 85°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | - | 0.354" Dia x 0.945" L (9.00mm x 24.00mm) | - | - | Through Hole | |
|
PEG130KJ4300QE4CAP ALUM 3000UF 40V AXIAL TH |
2,712 |
|
Datasheet | PEG130 | Tray | Active | 3000 µF | -10%, +30% | 40 V | 42mOhm @ 100Hz | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.85 A @ 100 Hz | 10.7 A @ 5 kHz | - | - | 0.787" Dia x 1.457" L (20.00mm x 37.00mm) | - | - | Through Hole | |
|
|
TE1509CAP ALUM 20UF 150V AXIAL TH |
369 |
|
Datasheet | TE | Bulk | Active | 20 µF | -10%, +50% | 150 V | - | 2000 Hrs @ 85°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | - | 0.354" Dia x 1.496" L (9.00mm x 38.00mm) | - | - | Through Hole | |
|
PEH534VDC3220M2CAP ALUM 220UF 20% 400V SNAP TH |
586 |
|
Datasheet | PEH534 | Bulk | Active | 220 µF | ±20% | 400 V | 460mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.1 A @ 100 Hz | - | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
PEH227MLL4110QE4CAP ALUM 1100UF 63V SOLDER LUG |
480 |
|
Datasheet | PEH227 | Bulk | Active | 1100 µF | -10%, +30% | 63 V | 77mOhm @ 100Hz | 2000 Hrs @ 150°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 1.925 A @ 100 Hz | 5.72 A @ 100 kHz | - | 0.600" (15.24mm) | 0.717" Dia (18.20mm) | 1.130" (28.70mm) | - | Through Hole | |
|
PEG130HL4630QE4CAP ALUM 6300UF 25V AXIAL TH |
1,076 |
|
Datasheet | PEG130 | Bulk | Active | 6300 µF | -10%, +30% | 25 V | 30mOhm @ 100Hz | 45000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 857.5 mA @ 100 Hz | 12.1 A @ 5 kHz | - | - | 0.787" Dia x 1.811" L (20.00mm x 46.00mm) | - | - | Through Hole | |
|
ALF80C102DF250CAP ALUM 1000UF 20% 250V PRESS |
978 |
|
Datasheet | ALF80 | Bulk | Active | 1000 µF | ±20% | 250 V | 178.2mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.46 A @ 100 Hz | 7.52 A @ 10 kHz | 106 mOhms | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole, Press-Fit | |
|
|
PEG228HKL4210ME4CAP ALUM 2100UF 20% 25V AXIAL TH |
478 |
|
Datasheet | PEG228 | Tray | Active | 2100 µF | ±20% | 25 V | 58mOhm @ 100Hz | 1500 Hrs @ 150°C | -40°C ~ 150°C | Polar | AEC-Q200 | Automotive | 2.135 A @ 100 Hz | 6.1 A @ 5 kHz | - | - | 0.638" Dia x 1.051" L (16.20mm x 26.70mm) | - | - | Through Hole | |
|
|
PEH227HLL4430QE4CAP ALUM 4300UF 25V SOLDER LUG |
480 |
|
Datasheet | PEH227 | Bulk | Active | 4300 µF | -10%, +30% | 25 V | 37mOhm @ 100Hz | 2000 Hrs @ 150°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 2.45 A @ 100 Hz | 7.28 A @ 100 kHz | - | 0.600" (15.24mm) | 0.717" Dia (18.20mm) | 1.130" (28.70mm) | - | Through Hole | |
|
|
PEG227MKL3780QE4CAP ALUM 780UF 63V AXIAL TH |
1,053 |
|
Datasheet | PEG227 | Tray | Active | 780 µF | -10%, +30% | 63 V | 107mOhm @ 100Hz | 1500 Hrs @ 150°C | -40°C ~ 150°C | Polar | AEC-Q200 | Automotive | 1.61 A @ 100 Hz | 4.6 A @ 5 kHz | - | - | 0.638" Dia x 1.051" L (16.20mm x 26.70mm) | - | - | Through Hole | |
|
ALC40A331CF400CAP ALUM 330UF 20% 400V SNAP TH |
1,431 |
|
Datasheet | ALC40 | Bulk | Active | 330 µF | ±20% | 400 V | 383mOhm @ 100Hz | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.98 A @ 100 Hz | 4.02 A @ 10 kHz | 258 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
PEV227HKL4320ME4CAP ALUM 3200UF 20% 25V SMD |
200 |
|
Datasheet | PEV227 | Tray | Active | 3200 µF | ±20% | 25 V | 49mOhm @ 100Hz | 6300 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 6.02 A @ 100 Hz | 17.888 A @ 100 kHz | - | - | 0.669" L x 0.669" W (17.00mm x 17.00mm) | 1.181" (30.00mm) | 1.024" L x 1.024" W (26.00mm x 26.00mm) | Surface Mount | |
|
ALC70A471DC350CAP ALUM 470UF 20% 350V SNAP TH |
496 |
|
Datasheet | ALC70 | Bulk | Active | 470 µF | ±20% | 350 V | 301.5mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.25 A @ 100 Hz | 5.26 A @ 10 kHz | 158 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
PEV228MLL3750QE4CAP ALUM 750UF 63V SMD |
386 |
|
Datasheet | PEV228 | Tray | Active | 750 µF | -10%, +30% | 63 V | 94mOhm @ 100Hz | 2000 Hrs @ 150°C | -40°C ~ 150°C | Polar | AEC-Q200 | Automotive | 5.25 A @ 100 Hz | 15.6 A @ 100 kHz | - | - | - | 1.181" (30.00mm) | 0.748" L x 0.748" W (19.00mm x 19.00mm) | Surface Mount | |
|
|
TVA1211-E3CAP ALUM 1000UF 25V AXIAL TH |
151 |
|
Datasheet | TVA ATOM® | Bulk | Active | 1000 µF | - | 25 V | - | - | -40°C ~ 85°C | Polar | - | Audio | - | - | - | - | 0.485" Dia x 1.500" L (12.32mm x 38.10mm) | - | - | Through Hole | |
|
|
PEV227HLP4620QE4CAP ALUM 6200UF 25V SMD |
199 |
|
Datasheet | PEV227 | Tray | Active | 6200 µF | -10%, +30% | 25 V | 27mOhm @ 100Hz | 8400 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 7.56 A @ 100 Hz | 22.464 A @ 100 kHz | - | - | 0.748" L x 0.748" W (19.00mm x 19.00mm) | 1.496" (38.00mm) | 1.102" L x 1.102" W (28.00mm x 28.00mm) | Surface Mount | |
|
PEG227MLP4160QE4CAP ALUM 1600UF 63V AXIAL TH |
2,072 |
|
Datasheet | PEG227 | Tray | Active | 1600 µF | -10%, +30% | 63 V | 55mOhm @ 100Hz | 2000 Hrs @ 150°C | -40°C ~ 150°C | Polar | AEC-Q200 | Automotive | 2.345 A @ 100 Hz | 6.7 A @ 5 kHz | - | - | 0.717" Dia x 1.366" L (18.20mm x 34.70mm) | - | - | Through Hole | |
|
|
PEH227HKP4460ME4CAP ALUM 4600UF 20% 25V SLD LUG |
351 |
|
Datasheet | PEH227 | Tray | Active | 4600 µF | ±20% | 25 V | 35mOhm @ 100Hz | 1500 Hrs @ 150°C | -40°C ~ 150°C | Polar | AEC-Q200 | Automotive | 2.59 A @ 100 Hz | 7.696 A @ 100 kHz | - | 0.600" (15.24mm) | 0.638" Dia (16.20mm) | 1.445" (36.70mm) | - | Through Hole |
