Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Output Configuration | Output Type | Number of Regulators | Voltage - Input (Max) | Voltage - Output (Min/Fixed) | Voltage - Output (Max) | Voltage Dropout (Max) | Current - Output | Current - Quiescent (Iq) | Current - Supply (Max) | PSRR | Control Features | Protection Features | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LT3029IDE#TRPBFIC REG LINEAR POS ADJ 16DFN |
0 |
|
Datasheet | - | 16-WFDFN Exposed Pad | Tape & Reel (TR) | Active | Positive | Adjustable | 2 | 20V | 1.215V | 19.5V | 0.46V @ 500mA, 0.46V @ 500mA | 500mA, 500mA | - | - | 67dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | - | - | Surface Mount | 16-DFN (4x3) |
|
LT3029IMSE#TRPBFIC REG LINEAR POS ADJ 16MSOP |
0 |
|
Datasheet | - | 16-TFSOP (0.118", 3.00mm Width) Exposed Pad | Tape & Reel (TR) | Active | Positive | Adjustable | 2 | 20V | 1.215V | 19.5V | 0.46V @ 500mA, 0.46V @ 500mA | 500mA, 500mA | - | - | 67dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | - | - | Surface Mount | 16-MSOP-EP |
|
LT3022IDHC#TRPBFIC REG LINEAR POS ADJ 1A 16DFN |
0 |
|
Datasheet | - | 16-WFDFN Exposed Pad | Tape & Reel (TR) | Active | Positive | Adjustable | 1 | 10V | 0.2V | 9.5V | 0.285V @ 1A | 1A | 3.5 mA | 36 mA | 70dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | - | - | Surface Mount | 16-DFN (5x3) |
|
TPS7150QDRIC REG LINEAR 5V 500MA 8SOIC |
0 |
|
Datasheet | - | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 5V | - | 0.23V @ 500mA | 500mA | 350 µA | 460 µA | 55dB ~ 52dB (120Hz) | Enable, Power Good | Over Temperature, Reverse Polarity | -40°C ~ 125°C | - | - | Surface Mount | 8-SOIC |
|
RAA214020GNP#MD05.5V 2A LOW NOISE LDO, 10 LEAD 3 |
0 |
|
Datasheet | - | 10-VFDFN Exposed Pad | Tape & Reel (TR) | Obsolete | Positive | Adjustable | 1 | 5.5V | 0.9V | 4.96V | 0.54V @ 2A | 2A | 300 µA | - | 81dB ~ 50dB (120Hz ~ 1MHz) | Enable, Power Good | Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) | -40°C ~ 125°C (TA) | - | - | Surface Mount | 10-DFN (3x3) |
|
LT3062MPDCB#TRPBFIC REG LINEAR POS ADJ 200MA 8DFN |
0 |
|
Datasheet | - | 8-WFDFN Exposed Pad | Tape & Reel (TR) | Active | Positive | Adjustable | 1 | 45V | 0.6V | 40V | 0.53V @ 200mA | 200mA | 90 µA | 10 mA | 85dB (120Hz) | Soft Start | Over Current, Over Temperature, Reverse Polarity | -55°C ~ 150°C | - | - | Surface Mount | 8-DFN (2x3) |
|
MIC49300-0.9WR-TRIC REG LINEAR 0.9V 3A SPAK-5 |
0 |
|
Datasheet | - | SPAK-5 (5 Leads + Tab) | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 6.5V | 0.9V | - | 0.4V @ 3A | 3A | - | - | - | Enable | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Surface Mount | 5-SPAK |
|
|
MIC49300-1.5WR-TRIC REG LINEAR 1.5V 3A SPAK-5 |
0 |
|
Datasheet | - | SPAK-5 (5 Leads + Tab) | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 6.5V | 1.5V | - | 0.4V @ 3A | 3A | - | - | - | Enable | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Surface Mount | 5-SPAK |
|
|
MIC49300-1.8WR-TRIC REG LINEAR 1.8V 3A SPAK-5 |
0 |
|
Datasheet | - | SPAK-5 (5 Leads + Tab) | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 6.5V | 1.8V | - | 0.4V @ 3A | 3A | - | - | - | Enable | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Surface Mount | 5-SPAK |
|
LT3062MPMS8E#TRPBFIC REG LIN POS ADJ 200MA 8MSOP |
0 |
|
Datasheet | - | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | Tape & Reel (TR) | Active | Positive | Adjustable | 1 | 45V | 0.6V | 40V | 0.53V @ 200mA | 200mA | 90 µA | 10 mA | 85dB (120Hz) | Soft Start | Over Current, Over Temperature, Reverse Polarity | -55°C ~ 150°C | - | - | Surface Mount | 8-MSOP-EP |
|
MIC29371-12WTIC REG LINEAR 12V 750MA TO220-5 |
0 |
|
Datasheet | - | TO-220-5 | Tube | Active | Positive | Fixed | 1 | 26V | 12V | - | 0.75V @ 750mA | 750mA | 300 µA | 16 mA | - | Enable | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Through Hole | TO-220-5 |
|
MIC29371-12WUIC REG LINEAR 12V 750MA TO263-5 |
0 |
|
Datasheet | - | TO-263-6, D2PAK (5 Leads + Tab), TO-263BA | Tube | Active | Positive | Fixed | 1 | 26V | 12V | - | 0.75V @ 750mA | 750mA | 300 µA | 16 mA | - | Enable | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Surface Mount | TO-263-5 |
|
MIC29371-3.3WTIC REG LINEAR 3.3V 750MA TO220-5 |
0 |
|
Datasheet | - | TO-220-5 | Tube | Active | Positive | Fixed | 1 | 26V | 3.3V | - | - | 750mA | 300 µA | 16 mA | - | Enable | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Through Hole | TO-220-5 |
|
LP3852EMP-5.0IC REG LINEAR 5V 1.5A SOT223-5 |
0 |
|
Datasheet | - | TO-261-5, TO-261AB | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 7V | 5V | - | 0.44V @ 1.5A | 1.5A | 3 mA | 10 mA | 73dB ~ 57dB (120Hz) | Enable | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C | - | - | Surface Mount | SOT-223-5 |
|
|
LP3855EMP-3.3IC REG LINEAR 3.3V 1.5A SOT223-5 |
0 |
|
Datasheet | - | TO-261-5, TO-261AB | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 7V | 3.3V | - | 0.44V @ 1.5A | 1.5A | 3 mA | 10 mA | 73dB ~ 57dB (120Hz) | Enable | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C | - | - | Surface Mount | SOT-223-5 |
|
|
LP3855EMP-5.0IC REG LINEAR 5V 1.5A SOT223-5 |
0 |
|
Datasheet | - | TO-261-5, TO-261AB | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 7V | 5V | - | 0.44V @ 1.5A | 1.5A | 3 mA | 10 mA | 73dB ~ 57dB (120Hz) | Enable | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C | - | - | Surface Mount | SOT-223-5 |
|
|
MIC29371-12WU-TRIC REG LINEAR 12V 750MA TO263-5 |
0 |
|
Datasheet | - | TO-263-6, D2PAK (5 Leads + Tab), TO-263BA | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 26V | 12V | - | 0.75V @ 750mA | 750mA | 300 µA | 16 mA | - | Enable | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Surface Mount | TO-263-5 |
|
MIC68401YML-TRIC REG LINEAR POS ADJ 3A 16QFN |
0 |
|
Datasheet | - | 16-VQFN Exposed Pad | Tape & Reel (TR) | Active | Positive | Adjustable | 1 | 5.5V | 0.5V or Tracking | 5.5V | 0.5V @ 3A | 3A | - | - | - | Enable, Power On Reset, Power Sequencing | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | - | - | Surface Mount | 16-QFN (4x4) |
|
U5R7723312IC REG LIN POS ADJ 150MA TO100 |
0 |
|
Datasheet | - | TO-100-10 Metal Can | Tape & Reel (TR) | Obsolete | Positive | Adjustable | 1 | 40V | 2V | 37V | - | 150mA | - | - | - | Current Limit | Short Circuit | -55°C ~ 150°C | - | - | Through Hole | TO-100-10 |
|
|
LT3063MPDCB#TRPBFIC REG LINEAR POS ADJ 200MA 8DFN |
0 |
|
Datasheet | - | 8-WFDFN Exposed Pad | Tape & Reel (TR) | Active | Positive | Adjustable | 1 | 45V | 0.6V | 19V | 0.53V @ 200mA | 200mA | - | - | 85dB (120Hz) | Enable | Over Current, Over Temperature, Reverse Polarity | -55°C ~ 150°C | - | - | Surface Mount | 8-DFN (2x3) |
