Ferrite Beads and Chips
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Ratings | Operating Temperature | Mounting Type | Height (Max) | Size / Dimension | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
.jpg)
|
Z0805C241BSMSTFERRITE BEAD 240 OHM 0805 1LN |
0 |
|
Datasheet | Z-SMS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 240 Ohms @ 100 MHz | 600mA | 200mOhm | - | -55°C ~ 125°C | Surface Mount | 0.041" (1.05mm) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - |
.jpg)
|
Z0402C241ASMSTFERRITE BEAD 240 OHM 0402 1LN |
0 |
|
Datasheet | Z-SMS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 240 Ohms @ 100 MHz | 400mA | 330mOhm | - | -55°C ~ 125°C | Surface Mount | 0.022" (0.55mm) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
|
Z0402C601ESMSTFERRITE BEAD 600 OHM 0402 1LN |
0 |
|
Datasheet | Z-SMS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 600 Ohms @ 100 MHz | 300mA | 600mOhm | - | -55°C ~ 125°C | Surface Mount | 0.022" (0.55mm) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
|
Z0402C601ASMSTFERRITE BEAD 600 OHM 0402 1LN |
0 |
|
Datasheet | Z-SMS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 600 Ohms @ 100 MHz | 300mA | 580mOhm | - | -55°C ~ 125°C | Surface Mount | 0.022" (0.55mm) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
|
Z0402C121ASMSTFERRITE BEAD 120 OHM 0402 1LN |
0 |
|
Datasheet | Z-SMS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 120 Ohms @ 100 MHz | 500mA | 230mOhm | - | -55°C ~ 125°C | Surface Mount | 0.022" (0.55mm) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
|
Z0402C121ESMSTFERRITE BEAD 120 OHM 0402 1LN |
0 |
|
Datasheet | Z-SMS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 120 Ohms @ 100 MHz | 450mA | 240mOhm | - | -55°C ~ 125°C | Surface Mount | 0.022" (0.55mm) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
|
Z0402C241ESMSTFERRITE BEAD 240 OHM 0402 1LN |
0 |
|
Datasheet | Z-SMS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 240 Ohms @ 100 MHz | 400mA | 310mOhm | - | -55°C ~ 125°C | Surface Mount | 0.022" (0.55mm) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
Z0603C102ASMSTFERRITE BEAD 1 KOHM 0603 1LN |
0 |
|
Datasheet | Z-SMS | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 1 kOhms @ 100 MHz | 300mA | 600mOhm | - | -55°C ~ 125°C | Surface Mount | 0.037" (0.95mm) | 0.063" L x 0.032" W (1.60mm x 0.80mm) | - |
|
|
Z0603C102BSMSTFERRITE BEAD 1 KOHM 0603 1LN |
0 |
|
Datasheet | Z-SMS | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 1 kOhms @ 100 MHz | 200mA | 700mOhm | - | -55°C ~ 125°C | Surface Mount | 0.037" (0.95mm) | 0.063" L x 0.032" W (1.60mm x 0.80mm) | - |
|
|
Z0603C102FSMSTFERRITE BEAD 1 KOHM 0603 1LN |
0 |
|
Datasheet | Z-SMS | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 1 kOhms @ 100 MHz | 300mA | 350mOhm | - | -55°C ~ 125°C | Surface Mount | 0.037" (0.95mm) | 0.063" L x 0.032" W (1.60mm x 0.80mm) | - |
-,80.jpg)
|
Z0603C601ASMSTFERRITE BEAD 600 OHM 0603 1LN |
0 |
|
Datasheet | Z-SMS | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 600 Ohms @ 100 MHz | 350mA | 450mOhm | - | -55°C ~ 125°C | Surface Mount | 0.037" (0.95mm) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
|
|
Z0805C221APMSTFERRITE BEAD 220 OHM 0805 1LN |
0 |
|
Datasheet | Z-PMS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Power Line | 1 | 220 Ohms @ 100 MHz | 2A | 50mOhm | - | -55°C ~ 85°C | Surface Mount | 0.041" (1.05mm) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - |
|
|
Z0805C330ASMSTFERRITE BEAD 33 OHM 0805 1LN |
0 |
|
Datasheet | Z-SMS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 33 Ohms @ 100 MHz | 1.2A | 50mOhm | - | -55°C ~ 125°C | Surface Mount | 0.041" (1.05mm) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - |
|
|
Z0805C101ASMSTFERRITE BEAD 100 OHM 0805 1LN |
0 |
|
Datasheet | Z-SMS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 100 Ohms @ 100 MHz | 900mA | 100mOhm | - | -55°C ~ 125°C | Surface Mount | 0.041" (1.05mm) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - |
|
|
Z0805C220ASMSTFERRITE BEAD 22 OHM 0805 1LN |
0 |
|
Datasheet | Z-SMS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 22 Ohms @ 100 MHz | 1.2A | 50mOhm | - | -55°C ~ 125°C | Surface Mount | 0.041" (1.05mm) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - |
|
Z0402C330FPMSTFERRITE BEAD 33 OHM 0402 1LN |
0 |
|
Datasheet | Z-PMS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Power Line | 1 | 33 Ohms @ 100 MHz | - | - | - | -55°C ~ 125°C | Surface Mount | 0.022" (0.55mm) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
Z0402C182GSMSTFERRITE BEAD 1.8K OHM 0402 1LN |
0 |
|
Datasheet | Z-SMS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Signal Line | 1 | 1.8 kOhms @ 100 MHz | - | - | - | -55°C ~ 125°C | Surface Mount | 0.022" (0.55mm) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - |
|
|
Z0805C420APWSTFERRITE BEAD 42 OHM 0805 1LN |
0 |
|
Datasheet | Z-PWS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Power Line | 1 | 42 Ohms @ 100 MHz | 4A | 8mOhm | - | -40°C ~ 125°C | Surface Mount | 0.041" (1.05mm) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - |
|
|
Z0805C210BPWSTFERRITE BEAD 21 OHM 0805 1LN |
0 |
|
Datasheet | Z-PWS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Power Line | 1 | 21 Ohms @ 100 MHz | 6A | 4mOhm | - | -40°C ~ 125°C | Surface Mount | 0.041" (1.05mm) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - |
|
Z0603C102BPWZTFERRITE BEAD 1K OHM 0603 1LN |
63 |
|
Datasheet | Z-PWZ | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Power Line | 1 | 1 kOhms @ 100 MHz | 500mA | 350mOhm | - | -40°C ~ 125°C | Surface Mount | 0.035" (0.90mm) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - |
