DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Main Purpose | Outputs and Type | Voltage - Output | Current - Output | Voltage - Input | Regulator Topology | Frequency - Switching | Contents | Utilized IC / Part | Power - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DC3042AEVAL BOARD FOR LTC3310 |
0 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.2V | 10A | 2.25V ~ 5.5V | Buck | 2MHz | Board(s) | LTC3310 |
|
TPS43330EVMEVAL BOARD FOR TPS43330 |
3 |
|
Datasheet | - | Box | Active | DC/DC, Step Up or Down | 1 Non-Isolated Output | - | - | - | 2V ~ 40V | Buck-Boost | 150kHz ~ 600kHz | Board(s) | TPS43330 |
|
DC2616A-AEVAL BOARD FOR LTM4645 |
2 |
|
Datasheet | µModule® | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1V | 50A | 6V ~ 15V | Buck | 600kHz | Board(s) | LTM4645 |
|
DC901AEVAL BOARD FOR LTC3444 |
2 |
|
Datasheet | - | Box | Active | DC/DC, Step Up or Down | 1 Non-Isolated Output | - | 0.8V ~ 4.2V | 400mA | 3.1V ~ 5V | Buck-Boost | 1.5MHz | Board(s) | LTC3444 |
|
DC1310AEVAL BOARD FOR LTC3612 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | - | 3A | 2.25V ~ 5.5V | Buck | 2.25MHz | Board(s) | LTC3612 |
|
DC463AEVAL BOARD FOR LTC3700 |
0 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 2 Non-Isolated Outputs | - | 2.5V, 3.3V | 1A, 150mA | 5V ~ 9V | Buck | 550kHz | Board(s) | LTC3700 |
|
DC1159AEVAL BOARD FOR LTC3565 |
0 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | - | 1.25A | 2.5V ~ 5.5V | Buck | 2.25MHz | Board(s) | LTC3565 |
|
DC1610AEVAL BOARD FOR LTC3604 |
0 |
|
Datasheet | - | Tray | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.2V | 2.5A | 3.6V ~ 15V | Buck | 1MHz | Board(s) | LTC3604 |
|
DC2258AEVAL BOARD FOR LT3048 |
0 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 20V | 25mA | 2.7V ~ 4.8V | Boost | 1MHz | Board(s) | LT3048 |
|
TPS62366AEVM-757EVAL BOARD FOR TPS62366A |
5 |
|
Datasheet | DCS-Control™ | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 0.5V ~ 1.77V | 4A | 2.5V ~ 5.5V | Buck | 2.5MHz | Board(s) | TPS62366A |
|
LM3691TL-1.8EV/NOPBEVAL BOARD FOR LM3691 |
4 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.8V | 1A | 2.3V ~ 5.5V | Buck | 4MHz | Board(s) | LM3691 |
|
TPS546C20AEVM2-746EVAL BOARD FOR TPS546C20A |
4 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 0.9V | 70A | 5V ~ 18V | Buck | 500kHz | Board(s) | TPS546C20A |
|
TPS43351EVMEVAL BOARD FOR TPS43351 |
3 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 2 Non-Isolated Outputs | - | 3.3V, 5V | 2A, 4A | 4V ~ 40V | Buck | 240kHz, 400kHz, 600kHz | Board(s) | TPS43351 |
|
TPS43340EVMEVAL BOARD FOR TPS43340 |
3 |
|
Datasheet | - | Box | Active | DC/DC, Step Down with LDO | 4 Non-Isolated Outputs | - | 1.8V, 3.3V, 3.3V, 5V | 4.5A, 4.5A, 2.2A, 300mA | 4V ~ 40V | Buck | - | Board(s) | TPS43340 |
|
LM26003EVAL/NOPBEVAL BOARD FOR LM26003 |
3 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 3.3V | 3A | 4V ~ 38V | Buck | 300kHz | Board(s) | LM26003 |
|
LMS3635MQEVMEVAL BOARD FOR LMS3635Q1 |
3 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 5V | 3.5A | 3.5V ~ 36V | Buck | 400kHz | Board(s) | LMS3635-Q1 |
|
LM26001EVALEVAL BOARD FOR LM26001 |
2 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 3.3V | 1.5A | 4.5V ~ 38V | Buck | 305kHz | Board(s) | LM26001 |
|
LM2757TMEVEVAL BOARD FOR LM2757 |
2 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 4.1V, 4.5V or 5V | 180mA | 2.7V ~ 5.5V | Boost | 1.24MHz | Board(s) | LM2757 |
|
LM25085AMYEEVAL/NOPBEVAL BOARD FOR LM25085A |
2 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1V | 5A | 4.5V ~ 24V | Buck | 200kHz | Board(s) | LM25085A |
|
LM5140RWGEVMHDEVAL BOARD FOR LM5140Q1 |
2 |
|
Datasheet | - | Bulk | Active | DC/DC, Step Down | 2 Non-Isolated Outputs | - | 3.3V, 5V | 5A, 5A | 3.8V ~ 42V | Buck | 2.2MHz | Board(s) | LM5140-Q1 |
