TVS Diodes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TPSMB300CA-VRTVS DIODE 256VWM 414V DO214 TR13 |
6,272 |
|
Datasheet | DO-214AA, SMB | TPSMB | Tape & Reel (TR) | Active | Zener | - | 1 | 256V | 285V | 414V | 1.5A | 600W | No | - | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-214AA (SMBJ) |
|
|
TPSMB350CA-VRTVS DIODE 300VWM 482VC DO214 TR |
5,987 |
|
Datasheet | DO-214AA, SMB | TPSMB | Tape & Reel (TR) | Active | Zener | - | 1 | 300V | 332V | 482V | 1.3A | 600W | No | - | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-214AA (SMBJ) |
|
1.5SMC350CTVS SMC 284V 1500W BIDIR |
9,117 |
|
Datasheet | DO-214AB, SMC | 1.5SMC | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 300V | 315V | 506.1V | 3.2A | 1500W (1.5kW) | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AB (SMCJ) |
|
1.5KE27ATVS DIODE 23.1VWM 37.5VC AXIAL |
5,223 |
|
Datasheet | DO-201AD, Axial | Mosorb™ | Bulk | Obsolete | Zener | 1 | - | 23.1V | 25.7V | 37.5V | 40A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 175°C (TJ) | - | - | Through Hole | Axial |
|
|
1.5KE30ATVS DIODE 25.6VWM 41.4VC AXIAL |
5,498 |
|
Datasheet | DO-201AD, Axial | Mosorb™ | Bulk | Obsolete | Zener | 1 | - | 25.6V | 28.5V | 41.4V | 36A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 175°C (TJ) | - | - | Through Hole | Axial |
|
TRA2532TVS DIODE 23VWM MICRODE BUTTON |
5,397 |
|
- |
Microde Button | - | Bulk | Obsolete | Zener | 1 | - | 23V | 24V | - | - | - | No | General Purpose | - | -65°C ~ 175°C (TJ) | - | - | Surface Mount | Microde Button |
|
SMBJ45A-13TVS DIODE 45VWM 72.7VC SMB |
4,339 |
|
- |
DO-214AA, SMB | SMBJ | Tape & Reel (TR) | Discontinued at Digi-Key | Zener | 1 | - | 45V | 50V | 72.7V | 8.3A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
|
|
SMBJ51A-13TVS DIODE 51VWM 82.4VC SMB |
6,478 |
|
- |
DO-214AA, SMB | SMBJ | Tape & Reel (TR) | Discontinued at Digi-Key | Zener | 1 | - | 51V | 56.7V | 82.4V | 7.3A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
|
|
SMBJ60A-13TVS DIODE 60VWM 96.8VC SMB |
9,372 |
|
- |
DO-214AA, SMB | SMBJ | Tape & Reel (TR) | Discontinued at Digi-Key | Zener | 1 | - | 60V | 66.7V | 96.8V | 6.2A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
|
|
SMBJ75A-13TVS DIODE 75VWM 121VC SMB |
9,429 |
|
- |
DO-214AA, SMB | SMBJ | Tape & Reel (TR) | Discontinued at Digi-Key | Zener | 1 | - | 75V | 83.3V | 121V | 4.9A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
|
|
SMBJ8.0A-13TVS DIODE 8VWM 13.6VC SMB |
9,027 |
|
- |
DO-214AA, SMB | SMBJ | Tape & Reel (TR) | Discontinued at Digi-Key | Zener | 1 | - | 8V | 8.89V | 13.6V | 44.1A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
|
|
SMBJ90A-13TVS DIODE 90VWM 146VC SMB |
6,847 |
|
- |
DO-214AA, SMB | SMBJ | Tape & Reel (TR) | Discontinued at Digi-Key | Zener | 1 | - | 90V | 100V | 146V | 4.1A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
|
|
SMCJ54CAQ-13-FTRANSIENT VOLTAGE SUPPRESSOR PP |
8,466 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Active | Zener | - | 1 | 54V | 60V | 87.1V | 17.2A | 1500W (1.5kW) | No | - | - | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
1.5SMC12AT3TVS DIODE 10.2VWM 16.7VC SMC |
5,062 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 10.2V | 11.4V | 16.7V | 90A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMC |
|
|
1.5SMC20AT3TVS DIODE 17.1VWM 27.7VC SMC |
7,932 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 17.1V | 19V | 27.7V | 54A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMC |
|
|
1.5SMC22AT3TVS DIODE 18.8VWM 30.6VC SMC |
6,475 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 18.8V | 20.9V | 30.6V | 49A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMC |
|
|
1.5SMC91AT3TVS DIODE 77.8VWM 125VC SMC |
6,577 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 77.8V | 86.5V | 125V | 12A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMC |
|
|
1SMC13AT3TVS DIODE 13VWM 21.5VC SMC |
3,461 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 13V | 14.4V | 21.5V | 69.7A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMC |
|
|
1SMC22AT3TVS DIODE 22VWM 35.5VC SMC |
3,574 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 22V | 24.4V | 35.5V | 42.2A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMC |
|
|
1SMC54AT3TVS DIODE 54VWM 87.1VC SMC |
5,490 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 54V | 60V | 87.1V | 17.2A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMC |
