TVS Diodes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
30KPA30CATVS DIODE 30VWM 55.2VC P600 |
718 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 30V | 33.51V | 55.2V | 548.9A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA102CATVS DIODE 102VWM 165.6VC P600 |
465 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 102V | 113.9V | 165.6V | 183A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA54CATVS DIODE 54VWM 91.4VC P600 |
343 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 54V | 60.3V | 91.4V | 331.5A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA33CATVS DIODE 33VWM 58.5VC P600 |
1,352 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 33V | 36.9V | 58.5V | 517.9A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA60CATVS DIODE 60VWM 102VC P600 |
800 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 60V | 67V | 102V | 297.1A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA90CATVS DIODE 90VWM 146.4VC P600 |
1,623 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 90V | 100.5V | 146.4V | 207A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA48CATVS DIODE 48VWM 81.6VC P600 |
612 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 48V | 53.6V | 81.6V | 371.3A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA36ATVS DIODE 36VWM 61.8VC P600 |
800 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | 1 | - | 36V | 40.2V | 61.8V | 490.3A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA58CATVS DIODE 58VWM 92.4VC P600 |
443 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 58V | 64.8V | 92.4V | 327.9A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA198CATVS DIODE 198VWM 319.8VC P600 |
639 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 198V | 221.2V | 319.8V | 94.7A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA216CATVS DIODE 216VWM 348.6VC P600 |
1,591 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 216V | 241.3V | 348.6V | 86.9A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA240CATVS DIODE 240VWM 387VC P600 |
1,476 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 240V | 268.1V | 387V | 78.3A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA180CATVS DIODE 180VWM 290.4VC P600 |
697 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 180V | 201.1V | 290.4V | 104.3A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
|
30KPA300CATVS DIODE 300VWM 484VC P600 |
769 |
|
Datasheet | P600, Axial | 30KPA | Tape & Reel (TR) | Active | Zener | - | 1 | 300V | 334V | 484V | 62A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | P600 |
|
MART100KP48ATVS DIODE 48VWM 94.3VC CASE 5A |
104 |
|
Datasheet | DO-204AR, Axial | - | Bulk | Active | Zener | 1 | - | 48V | 53.3V | 94.3V | - | 100000W (100kW) | No | General Purpose | - | -65°C ~ 150°C (TJ) | Military | MIL-PRF-19500 | Through Hole | Case 5A (DO-204AR) |
|
AK3-380CTVS DIODE 380VWM 520VC AXIAL |
53 |
|
Datasheet | Axial, Right Angle Bend (24.15mm Center) | AK3 | Bulk | Active | Zener | - | 1 | 380V | 401V | 520V | 3000A (3kA) (8/20µs) | - | No | General Purpose | 2000pF @ 10kHz | -55°C ~ 125°C (TJ) | - | - | Through Hole | Axial |
|
ESDZL5-1F4TVS DIODE 5.5VWM 10VC 0201 |
135,483 |
|
Datasheet | 0201 (0603 Metric) | ESDZ | Tape & Reel (TR) | Active | Zener | 1 | - | 5.5V (Max) | - | 10V | 7A (8/20µs) | 60W | No | General Purpose | 7.5pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 0201 |
|
ESD200B1CSP0201XTSA1TVS DIODE 5.5VWM 13VC |
76,922 |
|
Datasheet | 2-SMD, No Lead | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5.5V (Max) | 6V | 13V (Typ) | 16A (8/20µs) | - | No | General Purpose | 6.5pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | - |
|
ESD246B1W01005E6327XTSA1TVS DIODE 5.5VWM 7.5VC WLL-2-2 |
74,863 |
|
Datasheet | 01005 (0402 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5.5V | - | 7.5V | 5.5A (8/20µs) | 44W | No | General Purpose | 5.5pF @ 1GHz | -55°C ~ 125°C | - | - | Surface Mount | SG-WLL-2-2 |
|
ESD5Z3.3T5GTVS DIODE 3.3VWM 14.1VC SOD523 |
63,418 |
|
Datasheet | SC-79, SOD-523 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 3.3V (Max) | 5V | 14.1V | 11.2A (8/20µs) | 158W | No | General Purpose | 105pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-523 |
