Analog to Digital Converters (ADC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Number of Bits | Sampling Rate (Per Second) | Number of Inputs | Input Type | Data Interface | Configuration | Ratio - S/H:ADC | Number of A/D Converters | Architecture | Reference Type | Voltage - Supply, Analog | Voltage - Supply, Digital | Features | Operating Temperature | Supplier Device Package | Mounting Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ADS54J20IRMPIC ADC 12BIT PIPELINED 72VQFN |
0 |
|
Datasheet | - | 72-VFQFN Exposed Pad | Tray | Active | 12 | 1G | 2 | Differential | JESD204B | ADC | - | 2 | Pipelined | Internal | 1.8V ~ 2V, 2.85V ~ 3.6V | 1.7V ~ 2V | Simultaneous Sampling | -40°C ~ 85°C | 72-VQFN (10x10) | Surface Mount | - | - |
|
|
ADS54J69IRMPTIC ADC 72VQFN |
0 |
|
Datasheet | - | 72-VFQFN Exposed Pad | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 72-VQFN (10x10) | Surface Mount | - | - |
|
ADS54J54IRGC25IC ADC 64VQFN |
0 |
|
Datasheet | - | 64-VFQFN Exposed Pad | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 64-VQFN (9x9) | Surface Mount | - | - |
|
ADC12D500RFIUTIC ADC 12BIT FOLD INTERP 292BGA |
0 |
|
Datasheet | - | 292-BBGA | Tray | Active | 12 | 1G | 2 | Differential | LVDS - Parallel | MUX-S/H-ADC | 1:1 | 2 | Folding Interpolating | Internal | 1.8V ~ 2V | 1.8V ~ 2V | Simultaneous Sampling | -40°C ~ 85°C | 292-BGA (27x27) | Surface Mount | - | - |
|
|
ADS5263IRGCT-NMIC ADC 16BIT PIPELINED 64VQFN |
0 |
|
Datasheet | - | 64-VFQFN Exposed Pad | Tape & Reel (TR) | Active | 16 | 100M | 4 | Differential | LVDS - Serial | S/H-ADC | 1:1 | 4 | Pipelined | External, Internal | 3V ~ 3.6V | 1.7V ~ 1.9V | Simultaneous Sampling | -40°C ~ 85°C | 64-VQFN (9x9) | Surface Mount | - | - |
|
|
ADS54J66IRMPTIC ADC 72VQFN |
0 |
|
Datasheet | - | 72-VFQFN Exposed Pad | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 72-VQFN (10x10) | Surface Mount | - | - |
|
|
ADS54J54IRGCTIC ADC 14BIT PIPELINED 64VQFN |
0 |
|
Datasheet | - | 64-VFQFN Exposed Pad | Tape & Reel (TR) | Active | 14 | 500M | 4 | Differential | JESD204B | S/H-ADC | 1:1 | 4 | Pipelined | External | 1.8V ~ 2V, 3.15V ~ 3.45V | 1.7V ~ 1.9V | Simultaneous Sampling | -40°C ~ 85°C | 64-VQFN (9x9) | Surface Mount | - | - |
|
AD9680BCPZRL7-820IC ADC 14BIT PIPELINED 64QFN |
0 |
|
Datasheet | - | 64-WFQFN Exposed Pad, CSP | Tape & Reel (TR) | Active | 14 | 820M | 2 | Differential | JESD204B | S/H-ADC | 1:1 | 2 | Pipelined | External, Internal | 1.25V, 2.5V | 1.22V ~ 1.28V | Simultaneous Sampling | -40°C ~ 85°C | 64-LFCSP (9x9) | Surface Mount | - | - |
|
ADADC85S-12/883BIC ADC 12BIT 32CDIP |
0 |
|
Datasheet | - | 32-CDIP (0.900", 22.86mm) | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 32-SBDIP-H | Through Hole | - | - |
|
AD9697BCPZRL7-1300IC ADC 14BIT PIPELINED 64LFCSP |
0 |
|
Datasheet | - | 64-WFQFN Exposed Pad, CSP | Tape & Reel (TR) | Active | 14 | 1.3G | 1 | Differential | SPI | ADC | 0:1 | 1 | Pipelined | Internal | 0.93V ~ 2.56V | 0.93V ~ 1.89V | Simultaneous Sampling | -40°C ~ 105°C | 64-LFCSP (9x9) | Surface Mount | - | - |
|
AD574AUD/883BIC ADC 12BIT SAR 28CDIP |
0 |
|
Datasheet | - | 28-CDIP (0.600", 15.24mm) | Tube | Active | 12 | - | 1 | Single Ended | Parallel | ADC | 0:1 | 1 | SAR | External, Internal | ±11.4V ~ 16.5V | 5V | - | -55°C ~ 125°C | 28-CDIP | Through Hole | Military | MIL-STD-883 |
|
|
AD9234BCPZRL7-1000IC ADC 12BIT PIPELINED 64LFCSP |
0 |
|
Datasheet | - | 64-WFQFN Exposed Pad, CSP | Tape & Reel (TR) | Active | 12 | 1G | 2 | Differential | JESD204B | S/H-ADC | 1:1 | 1 | Pipelined | Internal | 1.22V ~ 1.28V, 2.44V ~ 2.56V | 1.22V ~ 1.28V | - | -40°C ~ 85°C | 64-LFCSP (9x9) | Surface Mount | - | - |
|
AD9699BBPZRL-300014 BIT SINGLE 3GSPS ADC |
0 |
|
Datasheet | - | 196-LFBGA Exposed Pad | Tape & Reel (TR) | Active | 14 | 3G | 1 | Single Ended | JESD204B | S/H-ADC | 1:1 | 1 | Pipelined | External | 0.95V ~ 1V, 1.85V ~ 1.95V, 2.44V ~ 2.56V | 0.95V ~ 1V | - | -40°C ~ 105°C | 196-BGA-ED (12x12) | Surface Mount | - | - |
|
|
ADS54J40IRMPTIC ADC 72VQFN |
0 |
|
Datasheet | - | 72-VFQFN Exposed Pad | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 72-VQFN (10x10) | Surface Mount | - | - |
|
|
ADS54J64IRMPTIC ADC 14BIT PIPELINED 72VQFN |
0 |
|
Datasheet | - | 72-VFQFN Exposed Pad | Tape & Reel (TR) | Active | 14 | 1G | 4 | Differential | JESD204B | S/H-ADC | 1:1 | 4 | Pipelined | Internal | 1.1V ~ 1.2V, 1.8V ~ 2V | 1.1V ~ 1.2V | Simultaneous Sampling | - | 72-VQFN (10x10) | Surface Mount | - | - |
|
AD9694BCPZRL7-500IC ADC 14BIT PIPELINED 72LFCSP |
0 |
|
Datasheet | - | 72-VFQFN Exposed Pad, CSP | Tape & Reel (TR) | Active | 14 | 500M | 4 | Differential | JESD204B | S/H-ADC | 1:1 | 4 | Pipelined | Internal | 0.95V ~ 1V, 1.71V ~ 1.89V, 2.44V ~ 2.56V | 0.95V ~ 1V | Simultaneous Sampling | -40°C ~ 105°C | 72-LFCSP-VQ (10x10) | Surface Mount | - | - |
|
ADC12J1600NKERIC ADC 12BIT FOLD INTERP 68VQFN |
0 |
|
Datasheet | - | 68-VFQFN Exposed Pad | Tape & Reel (TR) | Active | 12 | 1.6G | 1 | Differential | JESD204B | S/H-ADC | 1:1 | 1 | Folding Interpolating | Internal | 1.14V ~ 1.26V, 1.8V ~ 2V | 1.14V ~ 1.26V | - | -40°C ~ 85°C | 68-VQFN (10x10) | Surface Mount | - | - |
|
|
ADADC85SZ-12/883BIC ADC 12BIT |
0 |
|
Datasheet | - | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
AD9699WBBPZRL-300014 BIT SINGLE 3GSPS ADC |
0 |
|
- |
- | 196-LFBGA Exposed Pad | Tape & Reel (TR) | Active | 14 | 3G | 1 | Single Ended | JESD204B | S/H-ADC | 1:1 | 1 | Pipelined | External | 0.95V ~ 1V, 1.85V ~ 1.95V, 2.44V ~ 2.56V | 0.95V ~ 1V, 1.85V ~ 1.95V | - | -40°C ~ 105°C | 196-BGA-ED (12x12) | Surface Mount | Automotive | AEC-Q100 |
|
|
ADS54J60IRMPTIC ADC 16BIT PIPELINED 72VQFN |
0 |
|
Datasheet | - | 72-VFQFN Exposed Pad | Tape & Reel (TR) | Active | 16 | 1G | 2 | Differential | JESD204B | S/H-ADC | 1:1 | 2 | Pipelined | External | 1.8V ~ 2V, 2.85V ~ 3.6V | 1.7V ~ 2V | Simultaneous Sampling | -40°C ~ 85°C | 72-VQFN (10x10) | Surface Mount | - | - |
