SCRs - Modules
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Structure | Number of SCRs, Diodes | Voltage - Off State | Current - On State (It (AV)) (Max) | Current - On State (It (RMS)) (Max) | Voltage - Gate Trigger (Vgt) (Max) | Current - Gate Trigger (Igt) (Max) | Current - Non Rep. Surge 50, 60Hz (Itsm) | Current - Hold (Ih) (Max) | Operating Temperature | Grade | Qualification | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TT780N18KOFXPSA1THYR / DIODE MODULE DK |
6,366 |
|
Datasheet | TT | Module | Tray | Active | Series Connection - All SCRs | 2 SCRs | 1.8 kV | 775 A | 1050 A | 2 V | 250 mA | 23500A @ 50Hz | 300 mA | 135°C (TJ) | - | - | Chassis Mount |
|
|
TD700N22KOFXPSA1THYR / DIODE MODULE DK |
4,285 |
|
Datasheet | TD | Module | Tray | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 2.2 kV | 700 A | 1050 A | 2.2 V | 250 mA | 20400A @ 50Hz | 300 mA | 135°C (TJ) | - | - | Chassis Mount |
|
TD700N22KOFHPSA1THYR / DIODE MODULE DK |
8,325 |
|
Datasheet | - | Module | Tray | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 2.2 kV | 700 A | 1050 A | 2.2 V | 250 mA | 20400A @ 50Hz | 300 mA | 135°C (TJ) | - | - | Chassis Mount |
|
|
TT400N26KOFHPSA1SCR MODULE 2.6KV 800A MODULE |
2,894 |
|
Datasheet | - | Module | Tray | Active | Series Connection - All SCRs | 2 SCRs | 2.6 kV | 510 A | 800 A | 2.2 V | 250 mA | 13000A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Chassis Mount |
|
|
T930N36TOFVTXPSA1SCR MODULE 3600V 2200A DO200AC |
4,146 |
|
Datasheet | - | TO-200AC | Tray | Active | Single | 1 SCR | 3.6 kV | 930 A | 2200 A | 2.2 V | 250 mA | 19500A @ 50Hz | 500 mA | -40°C ~ 120°C | - | - | Clamp On |
|
|
STT1400N16P55HPSA1THYR / DIODE MODULE DK |
2,052 |
|
Datasheet | TT | Module | Tray | Active | 1-Phase Controller - All SCRs | 2 SCRs | 1.6 kV | - | - | 2 V | 200 mA | 10500A @ 50Hz | 300 mA | 125°C (TJ) | - | - | Chassis Mount |
|
T1190N12TOFVTXPSA1SCR MODULE 1800V 2800A DO200AC |
3,820 |
|
Datasheet | - | TO-200AC | Tray | Obsolete | Single | 1 SCR | 1.8 kV | 1190 A | 2800 A | 2 V | 250 mA | 22500A @ 50Hz | 500 mA | -40°C ~ 125°C | - | - | Clamp On |
|
|
TT600N16KS20HPSA1THYR / DIODE MODULE DK |
2,944 |
|
- |
- | - | Tray | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
TT700N22KOFXPSA1THYR / DIODE MODULE DK |
9,262 |
|
Datasheet | TT | Module | Tray | Active | Series Connection - All SCRs | 2 SCRs | 2.2 kV | 700 A | 1050 A | 2.2 V | 250 mA | 20400A @ 50Hz | 300 mA | 135°C (TJ) | - | - | Chassis Mount |
|
TD500N16KOFTIMHPSA1SCR MODULE 1800V 900A MODULE |
3,603 |
|
Datasheet | - | Module | Tray | Obsolete | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.8 kV | 500 A | 900 A | 2.2 V | 250 mA | 17000A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Chassis Mount |
|
STT1400N18P55XPSA1THYR / DIODE MODULE DK |
5,584 |
|
Datasheet | - | Module | Tray | Active | 1-Phase Controller - All SCRs | 2 SCRs | 1.8 kV | - | - | 2 V | 200 mA | 10500A @ 60Hz | 300 mA | 125°C (TJ) | - | - | Chassis Mount |
|
|
TT500N16KOFTIMHPSA1SCR MODULE 1800V 900A MODULE |
4,675 |
|
Datasheet | - | Module | Tray | Obsolete | Series Connection - SCR/Diode | 2 SCRs | 1.8 kV | 500 A | 900 A | 2.2 V | 250 mA | 17000A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Chassis Mount |
|
STT1400N16P55XPSA1SCR MODULE POWERBLOCK PS55-1 |
6,838 |
|
Datasheet | - | Module | Tray | Discontinued at Digi-Key | 1-Phase Controller - All SCRs | 2 SCRs | 1.6 kV | - | - | 2 V | 200 mA | 10500A @ 50Hz | 300 mA | 125°C (TJ) | - | - | Chassis Mount |
|
|
STT1400N18P55XPSA2THYR / DIODE MODULE DK |
4,071 |
|
Datasheet | TT | Module | Tray | Discontinued at Digi-Key | 1-Phase Controller - All SCRs | 2 SCRs | 1.8 kV | - | - | 2 V | 200 mA | 10500A @ 50Hz | 300 mA | 125°C (TJ) | - | - | Chassis Mount |
|
|
T1040N22TOFVTXPSA1SCR MODULE 2200V 2200A DO200AC |
2,317 |
|
Datasheet | - | TO-200AC | Tray | Obsolete | Single | 1 SCR | 2.2 kV | 1040 A | 2200 A | 2.2 V | 250 mA | 21500A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
|
TT700N22KOFHPSA1THYR / DIODE MODULE DK |
3,176 |
|
Datasheet | - | Module | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 2.2 kV | 700 A | 1050 A | 2.2 V | 250 mA | 20400A @ 50Hz | 300 mA | 135°C (TJ) | - | - | Chassis Mount |
|
|
TT820N16KS20HPSA1THYR / DIODE MODULE DK |
5,018 |
|
- |
- | - | Tray | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
T2510N04TOFVTXPSA1SCR MODULE 600V 4900A DO200AC |
2,757 |
|
Datasheet | - | TO-200AC | Tray | Discontinued at Digi-Key | Single | 1 SCR | 600 V | 2510 A | 4900 A | 1.5 V | 250 mA | 46000A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
TZ860N16KOFTIMHPSA1SCR MODULE 1600V 1500A MODULE |
8,603 |
|
Datasheet | - | Module | Tray | Active | Single | 1 SCR | 1.6 kV | 860 A | 1500 A | 2 V | 250 mA | 46000A @ 50Hz | 500 mA | 125°C (TJ) | - | - | Chassis Mount |
|
|
STT1900N16P55XPSA2THYR / DIODE MODULE DK |
4,510 |
|
Datasheet | TT | Module | Tray | Active | 1-Phase Controller - All SCRs | 2 SCRs | 1.6 kV | - | - | 2 V | 200 mA | 17000A @ 50Hz | 300 mA | 125°C (TJ) | - | - | Chassis Mount |
