Pin Configurable/Selectable Oscillators
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Base Resonator | Type | Frequency - Output 1 | Frequency - Output 2 | Frequency - Output 3 | Frequency - Output 4 | Function | Output | Voltage - Supply | Frequency Stability | Operating Temperature | Current - Supply (Max) | Ratings | Size / Dimension | Height | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
564CAED002004BCGOSCILLATOR SMD |
5,356 |
|
Datasheet | Ultra™ Si564 | 8-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | 10MHz, 20MHz | - | - | - | Enable/Disable | CMOS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 85°C | 135mA | - | 0.197" L x 0.126" W (5.00mm x 3.20mm) | 0.052" (1.33mm) | - |
|
|
544BAEB002092BCGOSCILLATOR SMD |
8,632 |
|
Datasheet | Ultra™ Si544 | 8-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | 100MHz | 100MHz, 195.3125MHz | - | - | Enable/Disable | LVDS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 85°C | 111mA | - | 0.197" L x 0.126" W (5.00mm x 3.20mm) | 0.052" (1.33mm) | - |
|
561BAA001109BCGOSCILLATOR SMD |
9,091 |
|
Datasheet | Ultra™ Si561 | 6-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | 2.2GHz, 2.4GHz | - | - | - | Enable/Disable | LVDS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 85°C | 130mA | - | 0.197" L x 0.126" W (5.00mm x 3.20mm) | 0.052" (1.33mm) | - |
|
|
549BAHC001943BCGOSCILLATOR SMD |
9,559 |
|
Datasheet | Ultra™ Si549 | 8-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | 26MHz, 27MHz | - | - | - | Enable/Disable | LVDS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 85°C | 121mA | - | 0.197" L x 0.126" W (5.00mm x 3.20mm) | 0.052" (1.33mm) | - |
|
|
564DAJA002017BCGROSCILLATOR SMD |
2,522 |
|
Datasheet | Ultra™ Si564 | 8-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | 2.875GHz, 2.877875GHz, 2.88363075GHz, 2.89516527GHz | - | - | - | Enable/Disable | CML | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 85°C | 130mA | - | 0.197" L x 0.126" W (5.00mm x 3.20mm) | 0.052" (1.33mm) | - |
|
544CAEC001910ACGROSCILLATOR SMD |
5,935 |
|
Datasheet | Ultra™ Si544 | 8-SMD, No Lead | Strip | Active | Crystal | XO (Standard) | 22.5792MHz, 24.576MHz | - | - | - | Enable/Disable | CMOS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 85°C | 108mA | - | 0.276" L x 0.197" W (7.00mm x 5.00mm) | 0.052" (1.33mm) | - |
|
DSA2311KA2-R0040VAOMEMS TWO-OUTPUT, AUTOMOTIVE, -40 |
4,109 |
|
Datasheet | DSA2311 | 6-VDFN | Tube | Active | MEMS | MEMS (Silicon) | 40MHz | 20MHz | - | - | Enable/Disable | LVCMOS | 3.3V | ±25ppm | -40°C ~ 125°C | - | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.035" (0.90mm) | 6-VDFN (2.5x2) |
|
|
CD-700-LAF-GAB-20M0000000CD-700-LAF-GAB-20M0000000 |
8,740 |
|
Datasheet | CD-700 | 16-CSMD, No Lead | Tape & Reel (TR) | Obsolete | Crystal | VCXO | 20MHz | 10MHz | - | - | Enable/Disable | CMOS | 3.3V | - | -40°C ~ 85°C | 63mA | - | 0.295" L x 0.200" W (7.49mm x 5.08mm) | 0.084" (2.13mm) | 16-CSMD (7.49x5.08) |
|
|
DSA2311KA2-R0040TVAOMEMS TWO-OUTPUT, AUTOMOTIVE, -40 |
5,376 |
|
Datasheet | DSA2311 | 6-VDFN | Tape & Reel (TR) | Active | MEMS | MEMS (Silicon) | 40MHz | 20MHz | - | - | Enable/Disable | LVCMOS | 3.3V | ±25ppm | -40°C ~ 125°C | - | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.035" (0.90mm) | 6-VDFN (2.5x2) |
|
|
CD-700-EAT-KDNN-24M7040000CD-700-EAT-KDNN-24M7040000 |
6,658 |
|
- |
CD-700 | 16-CSMD, No Lead | Tape & Reel (TR) | Obsolete | Crystal | VCXO | 24.704MHz | 1.544MHz | - | - | Enable/Disable | CMOS | - | - | - | 63mA | - | 0.295" L x 0.200" W (7.49mm x 5.08mm) | 0.084" (2.13mm) | 16-CSMD (7.49x5.08) |
|
DSC6121JI3B-01VJMEMS OSC. (FS), ULTRA LOW POWER, |
7,162 |
|
Datasheet | DSC61XXB | 4-VLGA | Tube | Active | MEMS | XO (Standard) | 130kHz, 132kHz | - | - | - | - | CMOS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 85°C | 3mA (Typ) | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.035" (0.89mm) | - |
|
|
DSC6023JL3B-01SHMEMS OSCILLATOR (FS), ULTRA LOW |
5,837 |
|
Datasheet | DSC60XXB | 4-VLGA | Tube | Active | MEMS | XO (Standard) | 24MHz, 25MHz | - | - | - | - | CMOS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 105°C | 1.3mA (Typ) | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.035" (0.89mm) | 4-VLGA (2.5x2) |
|
|
DSC6023MI2B-01TPMEMS OSC. (FS), ULTRA LOW POWER, |
5,702 |
|
Datasheet | DSC60XXB | 4-VFLGA | Bag | Active | MEMS | XO (Standard) | 24MHz, 48MHz | - | - | - | - | CMOS | 1.8V ~ 3.3V | ±25ppm | -40°C ~ 85°C | 1.3mA (Typ) | - | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.035" (0.89mm) | 4-VFLGA (2x1.6) |
|
|
DSA612RL3A-01W6VAO3-OUTPUT MEMS AUTOMOTIVE CLOCK G |
8,997 |
|
Datasheet | DSA612 | 6-VFLGA | Tube | Active | MEMS | MEMS (Silicon) | 32.768kHz | 25MHz | 32.768kHz | - | Enable/Disable | LVCMOS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 105°C | 6mA | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.035" (0.89mm) | 6-VFLGA (2.5x2) |
|
|
DSA2311KL1-R0096VAOMEMS TWO-OUTPUT, AUTOMOTIVE, -40 |
9,879 |
|
Datasheet | DSA2311 | 6-VDFN | Tube | Active | MEMS | XO (Standard) | 11.2896MHz | 14.7456MHz | - | - | Enable/Disable | LVCMOS | 3.3V | ±50ppm | -40°C ~ 105°C | - | AEC-Q100 | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.035" (0.90mm) | 6-VDFN (2.5x2) |
|
|
DSA2033FL2-F0022VAO100 LVDS X 2, -40-105C, 25PPM |
4,406 |
|
Datasheet | DSA20XX | 14-VFQFN Exposed Pad | Tube | Active | MEMS | MEMS (Silicon) | - | - | - | - | - | LVDS | 2.25V ~ 3.6V | ±25ppm | -40°C ~ 105°C | 23mA | - | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.035" (0.90mm) | 14-QFN (2.5x3.2) |
|
|
DSA2033FL2-F0022TVAO100 LVDS X 2, -40-105C, 25PPM |
6,393 |
|
Datasheet | DSA20XX | 14-VFQFN Exposed Pad | Tape & Reel (TR) | Active | MEMS | MEMS (Silicon) | - | - | - | - | - | LVDS | 2.25V ~ 3.6V | ±25ppm | -40°C ~ 105°C | 23mA | - | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.035" (0.90mm) | 14-QFN (2.5x3.2) |
|
|
DSA612RL3A-01W6TVAO3-OUTPUT MEMS AUTOMOTIVE CLOCK G |
8,746 |
|
Datasheet | DSA612 | 6-VFLGA | Tape & Reel (TR) | Active | MEMS | MEMS (Silicon) | 32.768kHz | 25MHz | 32.768kHz | - | Enable/Disable | LVCMOS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 105°C | 6mA | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.035" (0.89mm) | 6-VFLGA (2.5x2) |
|
|
DSA612RL3A-01YHVAO3-OUTPUT MEMS AUTOMOTIVE CLOCK G |
5,431 |
|
Datasheet | DSA612 | 6-VFLGA | Tube | Active | MEMS | XO (Standard) | 24MHz | 22.5792MHz | - | - | Enable/Disable | LVCMOS | 1.8V ~ 3.3V | ±20ppm | -40°C ~ 105°C | 6mA | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.035" (0.89mm) | 6-VFLGA (2.5x2) |
|
|
DSA2044FL2-H0006VAO156.25 HCSL X 2, -40-105C, 25PPM |
6,137 |
|
Datasheet | DSA20XX | 14-VFQFN Exposed Pad | Tube | Active | MEMS | MEMS (Silicon) | 156.25MHz | 156.25MHz | - | - | Enable/Disable | HCSL | 2.25V ~ 3.6V | ±25ppm | -40°C ~ 105°C | 49mA (Typ) | - | 0.098" L x 0.126" W (2.50mm x 3.20mm) | 0.035" (0.90mm) | 14-QFN (2.5x3.2) |
