IGBT Modules
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | IGBT Type | Configuration | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Power - Max | Vce(on) (Max) @ Vge, Ic | Current - Collector Cutoff (Max) | Input Capacitance (Cies) @ Vce | Input | NTC Thermistor | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FF450R12KE4EHOSA1IGBT MOD 1200V 520A 2400W |
19 |
|
- |
C | Module | Tray | Active | Trench Field Stop | 2 Independent | 1200 V | 520 A | 2400 W | 2.15V @ 15V, 450A | 5 mA | 28 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount | Module |
|
FF300R17KE4HOSA1IGBT MOD 1700V 440A 1800W |
11 |
|
- |
C | Module | Tray | Active | Trench Field Stop | 2 Independent | 1700 V | 440 A | 1800 W | 2.3V @ 15V, 300A | 1 mA | 24.5 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount | Module |
|
F3L11MR12W2M1B74BOMA1LOW POWER EASY |
14 |
|
- |
EasyPACK™ | Module | Tray | Active | Trench Field Stop | Three Level Inverter | 1200 V | 100 A | - | 1.5V @ 15V, 100A | 9 µA | 21.7 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | AG-EASY2B-2 |
|
FF450R12ME4B11BPSA2MEDIUM POWER ECONO AG-ECONOD-411 |
15 |
|
- |
EconoDUAL™ 3 | Module | Tray | Active | Trench Field Stop | 2 Independent | 1200 V | 675 A | 2250 W | 2.1V @ 15V, 450A | 3 mA | 28 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | AG-ECONOD |
|
FF450R12ME4BOSA1IGBT MOD 1200V 675A 2250W |
10 |
|
- |
- | Module | Tray | Active | Trench Field Stop | Half Bridge | 1200 V | 675 A | 2250 W | 2.1V @ 15V, 450A | 3 mA | 28 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
FS100R12KE3BOSA1IGBT MOD 1200V 140A 480W |
10 |
|
- |
- | Module | Tray | Not For New Designs | NPT | Single | 1200 V | 140 A | 480 W | 2.15V @ 15V, 100A | 5 mA | 7.1 nF @ 25 V | Standard | No | -40°C ~ 125°C (TJ) | Chassis Mount | Module |
|
|
FF600R12KE4PBOSA1IGBT MODULE 1200V |
2 |
|
- |
C | Module | Bulk | Active | Trench Field Stop | 2 Independent | 1200 V | 600 A | - | 2.2V @ 15V, 600A | 5 mA | 38 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | AG-62MM-1 |
|
FS150R06KE3BOSA1IGBT MOD 600V 150A 430W |
2 |
|
- |
- | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 600 V | 150 A | 430 W | 1.9V @ 15V, 150A | 1 mA | 9.3 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
FF300R12KS4HOSA1IGBT MOD 1200V 370A 1950W |
23 |
|
- |
C | Module | Tray | Active | - | 2 Independent | 1200 V | 370 A | 1950 W | 3.75V @ 15V, 300A | 5 mA | 20 nF @ 25 V | Standard | No | -40°C ~ 125°C | Chassis Mount | Module |
|
FF400R12KE3HOSA1IGBT MOD 1200V 580A 2000W |
20 |
|
- |
C | Module | Tray | Active | Trench Field Stop | Half Bridge | 1200 V | 580 A | 2000 W | 2.15V @ 15V, 400A | 5 mA | 28 nF @ 25 V | Standard | No | -40°C ~ 125°C (TJ) | Chassis Mount | Module |
|
FS200R06KE3BOSA1IGBT MOD 600V 200A 600W |
7 |
|
- |
EconoPACK™ 3 | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 600 V | 200 A | 600 W | 1.9V @ 15V, 200A | 1 mA | 13 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
FS150R12KT4B9BOSA1IGBT MOD 1200V 150A 750W |
6 |
|
- |
EconoPACK™ 3 | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 150 A | 750 W | 2.1V @ 15V, 150A | 1 mA | 9.35 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount | Module |
|
|
FF300R17KE3HOSA1IGBT MODULE 1700V 1450W |
15 |
|
- |
C | Module | Tray | Active | Trench Field Stop | 2 Independent | 1700 V | - | 1450 W | 2.45V @ 15V, 300A | 3 mA | 27 nF @ 25 V | Standard | No | -40°C ~ 125°C | Chassis Mount | Module |
|
FF600R12ME4BOSA1IGBT MODULE 1200V 4050W |
10 |
|
- |
EconoDUAL™ 3 | Module | Tray | Not For New Designs | Trench Field Stop | 2 Independent | 1200 V | - | 4050 W | 2.1V @ 15V, 600A | 3 mA | 37 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
FF900R12IP4BOSA2IGBT MOD 1200V 900A 5100W |
4 |
|
- |
PrimePack™2 | Module | Tray | Active | Trench Field Stop | Single | 1200 V | 900 A | 5100 W | 2.05V @ 15V, 900A | 5 mA | 54 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
FF900R12IE4PBOSA1IGBT MOD 1200V 900A 20MW |
6 |
|
- |
PrimePACK™2 | Module | Tray | Active | Trench Field Stop | Half Bridge | 1200 V | 900 A | - | 2.1V @ 15V, 900A | 5 mA | 54 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
FS450R17OP4BPSA1MEDIUM POWER ECONO AG-ECONOPP-2 |
4 |
|
- |
EconoPACK™+ | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1700 V | 450 A | - | 2.2V @ 15V, 450A | 3 mA | 37 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | AG-ECONOPP-2-1 |
|
FZ1200R12HP4HOSA2IGBT MOD 1200V 1790A 7150W |
2 |
|
- |
IHM-B | Module | Tray | Active | Trench | Single Switch | 1200 V | 1790 A | 7150 W | 2.05V @ 15V, 1200A | 5 mA | 74 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount | Module |
|
FZ2400R17HP4HOSA2IGBT MODULE 1700V 400A |
2 |
|
- |
IHM-B | Module | Tray | Active | - | Single Switch | 1700 V | 2400 A | 15500 W | 2.25V @ 15V, 2.4kA | 5 mA | 195 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | - |
|
|
FZ1600R17HP4B2BOSA2IGBT MODULE 1700V 1600A |
10 |
|
- |
IHM-B | Module | Tray | Active | Trench Field Stop | Single Switch | 1700 V | 1600 A | 10500 W | 2.25V @ 15V, 1.6kA | 5 mA | 130 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | A-IHV130-3 |
