Fuses
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Mounting Type | Fuse Type | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Response Time | Breaking Capacity @ Rated Voltage | Melting I²t | Approval Agency | Operating Temperature | Color | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
0312.031VFUSE GLASS 31MA 250VAC 3AB 3AG |
7,261 |
|
Datasheet | 312 | Bulk | Obsolete | Requires Holder | Cartridge, Glass | 31 mA | 250 V | - | Fast Blow | 35A | 3.0E-5 | CSA, UL | -55°C ~ 125°C | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
0277.375MFUSE BRD MT 375MA 125VAC/VDC AXL |
9,419 |
|
Datasheet | PICO® 277 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 375 mA | 125 V | 125 V | - | - | - | - | - | - | 0.093" Dia x 0.280" L (2.36mm x 7.11mm) | |
|
0253010.MFUSE BOARD MOUNT 10A 125VAC/VDC |
6,852 |
|
Datasheet | PICO® II 253 | Bulk | Discontinued at Digi-Key | Through Hole | Board Mount (Cartridge Style Excluded) | 10 A | 32 V | 32 V | Fast Blow | 50A AC, 300A DC | 25.5 | CSA, QPL, TUV, UR | -55°C ~ 125°C | - | 0.103" Dia x 0.280" L (2.61mm x 7.11mm) | |
|
0277.250NRT1FUSE BRD MT 250MA 125VAC/VDC AXL |
4,004 |
|
- |
PICO® 277 | Tape & Reel (TR) | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 250 mA | 125 V | 125 V | Fast Blow | - | - | - | - | - | 0.093" Dia x 0.280" L (2.36mm x 7.11mm) | |
|
|
0277.375NRT1FUSE BRD MT 375MA 125VAC/VDC AXL |
5,464 |
|
- |
PICO® 277 | Tape & Reel (TR) | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 375 mA | 125 V | 125 V | Fast Blow | - | - | - | - | - | 0.093" Dia x 0.280" L (2.36mm x 7.11mm) | |
|
3298125.HFUSE BRD MT 125A 32VDC MOD 100PC |
5,309 |
|
Datasheet | ZCASE® SMZ | Box | Active | Bolt Mount | Board Mount (Cartridge Style Excluded) | 125 A | - | 32 V | - | 2kA | 45000.0 | - | -40°C ~ 125°C | - | - | |
|
|
3298225.HFUSE BRD MT 225A 32VDC MOD 100PC |
8,154 |
|
Datasheet | ZCASE® SMZ | Box | Active | Bolt Mount | Board Mount (Cartridge Style Excluded) | 225 A | - | 32 V | - | 2kA | 95000.0 | - | -40°C ~ 125°C | - | - | |
|
|
0277.062NRT1FUSE BRD MNT 62MA 125VAC/VDC AXL |
9,054 |
|
- |
PICO® 277 | Tape & Reel (TR) | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 62 mA | 125 V | 125 V | Fast Blow | - | - | - | - | - | 0.093" Dia x 0.281" L (2.36mm x 7.14mm) | |
|
|
0313.062VXPFUSE GLASS 62MA 250VAC 3AB 3AG |
9,514 |
|
Datasheet | 313 | Bulk | Active | Requires Holder | Cartridge, Glass | 62 mA | 250 V | - | Slow Blow | 35A | 0.021 | CE, CSA, UL | -55°C ~ 125°C | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
0217.160VXPFUSE GLASS 160MA 250VAC 5X20MM |
8,070 |
|
Datasheet | 217 | Bulk | Active | Requires Holder | Cartridge, Glass | 160 mA | 250 V | - | Fast Blow | 35A | 0.01 | CCC, CE, CSA,KC, SEMKO, UL, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
0217.200VXPFUSE GLASS 200MA 250VAC 5X20MM |
8,950 |
|
Datasheet | 217 | Bulk | Active | Requires Holder | Cartridge, Glass | 200 mA | 250 V | - | Fast Blow | 35A | 0.02 | CCC, CE, CSA,KC, SEMKO, UL, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
0253.250VXLFUSE BRD MT 250MA 125VAC/VDC AXL |
2,539 |
|
Datasheet | PICO® II 253 | Bulk | Obsolete | Through Hole | Board Mount (Cartridge Style Excluded) | 250 mA | 125 V | 125 V | Fast Blow | 50A AC, 300A DC | 0.0116 | CSA, QPL, UR | -55°C ~ 125°C | - | 0.103" Dia x 0.280" L (2.61mm x 7.11mm) | |
|
0473004.VXLFUSE BRD MNT 4A 125VAC/VDC AXIAL |
7,847 |
|
Datasheet | PICO® II 473 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 4 A | 125 V | 125 V | Slow Blow | 50A | 35.0 | CSA, PSE, UR | -55°C ~ 125°C | - | 0.135" Dia x 0.280" L (3.43mm x 7.11mm) | |
|
|
0473003.VXLFUSE BRD MNT 3A 125VAC/VDC AXIAL |
5,619 |
|
Datasheet | PICO® II 473 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 3 A | 125 V | 125 V | Slow Blow | 50A | 21.0 | CSA, PSE, UR | -55°C ~ 125°C | - | 0.135" Dia x 0.280" L (3.43mm x 7.11mm) | |
|
0326.100VXPFUSE CERM 100MA 250VAC 3AB 3AG |
2,553 |
|
Datasheet | 326 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 100 mA | 250 V | - | Slow Blow | 100A | 0.087 | CE | -55°C ~ 125°C | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
|
0326.125VXPFUSE CERM 125MA 250VAC 3AB 3AG |
9,910 |
|
Datasheet | 326 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 125 mA | 250 V | - | Slow Blow | 100A | 0.1 | CE | -55°C ~ 125°C | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
|
0326.150VXPFUSE CERM 150MA 250VAC 3AB 3AG |
7,892 |
|
Datasheet | 326 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 150 mA | 250 V | - | Slow Blow | 100A | 0.143 | CE | -55°C ~ 125°C | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
0273.100VFUSE BOARD MNT 100MA 125VAC/VDC |
2,274 |
|
Datasheet | MICRO™ 273 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 100 mA | 125 V | 125 V | Fast Blow | 10kA | 3.85E-4 | CSA, QPL, UL | -55°C ~ 85°C | - | 0.250" Dia x 0.350" H (6.35mm x 8.89mm) | |
|
|
0273.125VFUSE BOARD MNT 125MA 125VAC/VDC |
7,821 |
|
Datasheet | MICRO™ 273 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 125 mA | 125 V | 125 V | Fast Blow | 10kA | 9.61E-4 | CSA, QPL, UL | -55°C ~ 85°C | - | 0.250" Dia x 0.350" H (6.35mm x 8.89mm) | |
|
|
0MEG080.XFUSE AUTO 80A 32VAC 32VDC |
7,157 |
|
Datasheet | MEGA® | Bulk | Active | Bolt Mount | Automotive | 80 A | 32 V | 32 V | Slow Blow | - | - | - | - | - | 1.149" L x 0.770" W x 0.390" H (29.20mm x 19.50mm x 9.90mm) |
