Fuses
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Mounting Type | Fuse Type | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Response Time | Breaking Capacity @ Rated Voltage | Melting I²t | Approval Agency | Operating Temperature | Color | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
0806030.WRFUSE BOARD MOUNT 30A 36VDC 2SMD |
85 |
|
Datasheet | 806 | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 30 A | - | 36 V | Fast Blow | 200A | 170.0 | cURus | -55°C ~ 150°C | - | 0.125" L x 0.064" W x 0.052" H (3.18mm x 1.63mm x 1.33mm) | |
|
0AGA003.VFUSE GLASS 3A 32VAC/VDC 1AG |
53 |
|
Datasheet | AGA | Bulk | Active | Requires Holder | Cartridge, Glass | 3 A | 32 V | 32 V | - | - | - | - | - | - | 0.250" Dia x 0.625" L (6.35mm x 15.88mm) | |
|
37203150411FUSE BRD MNT 315MA 250VAC RADIAL |
828 |
|
Datasheet | TR5® 372 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 315 mA | 250 V | - | Slow Blow | 35A | 0.3969 | CCC, cURus, SEMKO, VDE | -40°C ~ 85°C | - | 0.335" Dia x 0.315" H (8.50mm x 8.00mm) | |
|
0997030.WXNFUSE AUTO 30A 58VDC BLADE MINI |
588 |
|
Datasheet | MINI® 997 | Bulk | Active | Requires Holder | Automotive | 30 A | - | 58 V | Fast Blow | 1kA | 1130.0 | - | -40°C ~ 125°C | Green | 0.429" L x 0.150" W x 0.346" H (10.90mm x 3.80mm x 8.80mm) | |
|
0891002.HFUSE AUTOMOTIVE 2A 58VDC BLADE |
557 |
|
Datasheet | LP MINI® 891 | Bulk | Active | Requires Holder | Automotive | 2 A | - | 58 V | Fast Blow | 10kA | 3.0 | - | -40°C ~ 125°C | Gray | 0.429" L x 0.150" W x 0.331" H (10.90mm x 3.80mm x 8.40mm) | |
|
0997025.WXNFUSE AUTO 25A 58VDC BLADE MINI |
539 |
|
Datasheet | MINI® 997 | Bulk | Active | Requires Holder | Automotive | 25 A | - | 58 V | Fast Blow | 1kA | 625.0 | - | -40°C ~ 125°C | Clear | 0.429" L x 0.150" W x 0.346" H (10.90mm x 3.80mm x 8.80mm) | |
|
0891005.HFUSE AUTOMOTIVE 5A 58VDC BLADE |
90 |
|
Datasheet | LP MINI® 891 | Bulk | Active | Requires Holder | Automotive | 5 A | - | 58 V | Fast Blow | 10kA | 22.0 | - | -40°C ~ 125°C | Tan | 0.429" L x 0.150" W x 0.331" H (10.90mm x 3.80mm x 8.40mm) | |
|
0997005.WXNFUSE AUTOMOTIVE 5A 58VDC BLADE |
49 |
|
Datasheet | MINI® 997 | Bulk | Active | Requires Holder | Automotive | 5 A | - | 58 V | Fast Blow | 1kA | 25.0 | - | -40°C ~ 125°C | Tan | 0.429" L x 0.150" W x 0.346" H (10.90mm x 3.80mm x 8.80mm) | |
|
37212500001FUSE BOARD MNT 2.5A 250VAC RAD |
1,000 |
|
Datasheet | TR5® 372 | Cut Tape (CT) | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 2.5 A | 250 V | - | Slow Blow | 35A | 35.0 | CCC, cURus, PSE, SEMKO, VDE | -40°C ~ 85°C | - | 0.335" Dia x 0.315" H (8.50mm x 8.00mm) | |
|
38212000410FUSE BOARD MNT 2A 250VAC RADIAL |
912 |
|
Datasheet | TR5® 382 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 2 A | 250 V | - | Slow Blow | 100A | 17.8 | CCC, cURus, KC, PSE/JET, SEMKO, VDE | -40°C ~ 85°C | - | 0.335" Dia x 0.315" H (8.50mm x 8.00mm) | |
|
025102.5MAT1LFUSE BRD MNT 2.5A 125VAC/VDC AXL |
668 |
|
Datasheet | PICO® II 251 | Cut Tape (CT) | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 2.5 A | 125 V | 125 V | Fast Blow | 50A AC, 300A DC | 0.721 | CCC, CSA, cURus, PSE, TUV | -55°C ~ 125°C | - | 0.110" Dia x 0.280" L (2.80mm x 7.11mm) | |
|
|
37215000001FUSE BOARD MNT 5A 250VAC RADIAL |
612 |
|
Datasheet | TR5® 372 | Cut Tape (CT) | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 5 A | 250 V | - | Slow Blow | 50A | 115.0 | CCC, cURus, PSE, SEMKO, VDE | -40°C ~ 85°C | - | 0.335" Dia x 0.315" H (8.50mm x 8.00mm) | |
|
|
37401600410FUSE BRD MNT 160MA 250VAC RADIAL |
364 |
|
Datasheet | TR5® 374 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 160 mA | 250 V | - | Slow Blow | 50A | 0.058 | CSA, cULus | -40°C ~ 85°C | - | 0.335" Dia x 0.315" H (8.50mm x 8.00mm) | |
|
0229005.HXSPFUSE GLASS 5A 125VAC/VDC 2AG |
249 |
|
Datasheet | 229 | Bulk | Active | Requires Holder | Cartridge, Glass | 5 A | 125 V | 125 V | Slow Blow | 400A | 267.0 | CE, CSA, PSE, UL | -55°C ~ 125°C | - | 0.177" Dia x 0.570" L (4.50mm x 14.48mm) | |
|
|
37213150431FUSE BRD MNT 3.15A 250VAC RADIAL |
123 |
|
Datasheet | TR5® 372 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 3.15 A | 250 V | - | Slow Blow | 35A | 77.3955 | CCC, cURus, PSE, SEMKO, VDE | -40°C ~ 85°C | - | 0.335" Dia x 0.315" H (8.50mm x 8.00mm) | |
|
023301.6MXPFUSE GLASS 1.6A 125VAC 5X20MM |
950 |
|
Datasheet | 233 | Bulk | Active | Requires Holder | Cartridge, Glass | 1.6 A | 125 V | - | Medium Blow | 10kA | 6.14 | CE, CSA, KC, PSE, UL | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
.JPG)
|
0232010.MX125PFUSE GLASS 10A 125VAC 5X20MM |
820 |
|
Datasheet | 232 | Bulk | Active | Requires Holder | Cartridge, Glass | 10 A | 125 V | - | Medium Blow | 300A | 290.665 | CE, KC, PSE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
0233007.MXPFUSE GLASS 7A 125VAC 5X20MM |
763 |
|
Datasheet | 233 | Bulk | Active | Requires Holder | Cartridge, Glass | 7 A | 125 V | - | Medium Blow | 10kA | 157.31 | CE, PSE, UL | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
37214000411FUSE BOARD MNT 4A 250VAC RADIAL |
568 |
|
Datasheet | TR5® 372 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 4 A | 250 V | - | Slow Blow | 40A | 126.4 | CCC, cURus, PSE, SEMKO, VDE | -40°C ~ 85°C | - | 0.335" Dia x 0.315" H (8.50mm x 8.00mm) | |
|
|
023306.3MXPFUSE GLASS 6.3A 125VAC 5X20MM |
564 |
|
Datasheet | 233 | Bulk | Active | Requires Holder | Cartridge, Glass | 6.3 A | 125 V | - | Medium Blow | 10kA | 151.905 | CE, CSA, KC, PSE, UL | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) |
