DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Main Purpose | Outputs and Type | Voltage - Output | Current - Output | Voltage - Input | Regulator Topology | Frequency - Switching | Contents | Utilized IC / Part | Power - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DC2861AEVAL BOARD FOR LTM4658 |
2 |
|
Datasheet | µModule® | Bulk | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1V | 10A | 2.25V ~ 5.5V | Buck | 2MHz | Board(s) | LTM4658 |
|
DC1053A-GEVAL BOARD FOR LTC3526L2 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 1.8V, 3.3V or 5V | 100mA | 0.8V ~ 5.5V | Boost | 2MHz | Board(s) | LTC3526L-2 |
|
DC1219A-DEVAL BOARD FOR LT3495B1 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 15V | 36mA | 3V ~ 6V | Boost | - | Board(s) | LT3495B-1 |
|
DC1221BEVAL BOARD FOR LT3502 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 3.3V | 500mA | 4.5V ~ 40V | Buck | 1.1MHz | Board(s) | LT3502 |
|
DC1024A-AEVAL BOARD FOR LT3494 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 15V | 32mA | 3V ~ 4.2V | Boost | - | Board(s) | LT3494 |
|
DC1024A-BEVAL BOARD FOR LT3494A |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 15V | 44mA | 3V ~ 4.2V | Boost | - | Board(s) | LT3494A |
|
DC1209AEVAL BOARD FOR LT3060 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.2V ~ 5V | 100mA | 2.1V ~ 45V | Buck | - | Board(s) | LT3060 |
|
DC1311A-AEVAL BOARD FOR LTC3805 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Isolated Output | - | 3.3V | 3A | 18V ~ 72V | Flyback | 300kHz | Board(s) | LTC3805 |
|
DC437AEVAL BOARD FOR LT1964 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | -1.22V, -5V | 200mA | -2.3V ~ -20V | Buck | - | Board(s) | LT1964 |
|
DC1601B-AEVAL BOARD FOR LTM4607 |
1 |
|
Datasheet | µModule® | Box | Active | DC/DC, Step Up or Down | 1 Non-Isolated Output | - | 12V | 10A | 6V ~ 36V | Buck-Boost | 300kHz | Board(s) | LTM4607 |
|
DC2564AEVAL BOARD FOR LT8606 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 5V | 350mA | 5.5V ~ 42V | Buck | 2MHz | Board(s) | LT8606 |
|
DC2003AEVAL BOARD FOR LTC3622 |
1 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 2 Non-Isolated Outputs | - | 3.3V, 5V | 1A, 1A | 2.7V ~ 17V | Buck | - | Board(s) | LTC3622 |
|
ADP5600CP-EVALZEVAL BOARD FOR ADP5600 |
1 |
|
Datasheet | - | Bulk | Active | DC/DC, Negative Inverter | 2 Non-Isolated Outputs | - | - | - | 2.7V ~ 16V | Inverting | - | Board(s) | ADP5600 |
|
DC1863AEVAL BOARD FOR LTC3621 |
0 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.2V, 1.8V, 2.5V, 3.3V or 5V | 1A | 2.7V ~ 17V | Buck | 1MHz | Board(s) | LTC3621 |
|
DC1447AEVAL BOARD FOR LT3082 |
0 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Non-Isolated Output | - | 1.2V ~ 5V | 200mA | 2.8V ~ 35V | Buck | - | Board(s) | LT3082 |
|
TPS61085-Q1EVMEVAL BOARD FOR TPS61085Q1 |
4 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 12V | 600mA | 2.3V ~ 6V | Boost | - | Board(s) | TPS61085-Q1 |
|
LM5001ISOEVAL/NOPBEVAL BOARD FOR LM5001 |
3 |
|
Datasheet | - | Box | Active | DC/DC, Step Down | 1 Isolated Output | - | 5V | 1A | 16V ~ 42V | Flyback | 250kHz | Board(s) | LM5001 |
|
LM5114BSDEVAL/NOPBEVAL BOARD FOR LM5114 |
2 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 75V | 2A | 24V ~ 66V | Boost | 500kHz | Board(s) | LM5114 |
|
LM2700MT-ADJEV/NOPBEVAL BOARD FOR LM2700 |
2 |
|
Datasheet | - | Box | Active | DC/DC, Step Up | 1 Non-Isolated Output | - | 8V | 2.5A | 2.2V ~ 12V | Boost | - | Board(s) | LM2700 |
|
BD83070GWL-EVK-001EVAL BOARD FOR BD83070 |
2 |
|
Datasheet | - | Tube | Active | DC/DC, Step Up or Down | 1 Non-Isolated Output | - | 2.5V or 3.3V | 1A | 2V ~ 5.5V | Buck-Boost | 1.5MHz | Board(s) | BD83070 |
