Current Sense Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Frequency Range | Type | Current Rating (Amps) | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Current Ratio | DC Resistance (DCR) | Ratings | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CT-0050-F10CURR SENSE XFMR 50:5 FOOTED |
17 |
|
Datasheet | CT | Bulk | Active | - | Non-Invasive (Solid Core) | 50 A | - | - | - | 50:5 | - | - | - | - | - | Terminal Block |
|
CT-0150-D10CURR SENSE XFMR 150:5 DONUT |
11 |
|
Datasheet | CT | Bulk | Active | - | Non-Invasive (Solid Core) | 150 A | - | - | - | 150:5 | - | - | Free Hanging (In-Line) | - | - | Wire Leads |
|
CT-0050-D10CURR SENSE XFMR 50A IN-LINE |
8 |
|
Datasheet | - | Bulk | Active | - | Non-Invasive (Solid Core) | 50 A | - | - | - | 50:5 | - | - | Free Hanging (In-Line) | 2.461" Dia (62.50mm) | - | Wire Leads |
|
CT200CURR SENSE XFMR |
6 |
|
Datasheet | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
CT-0200-D10CURR SENSE XFMR 200:5 DONUT |
2 |
|
Datasheet | CT | Bulk | Active | - | Non-Invasive (Solid Core) | 200 A | - | - | - | 200:5 | - | - | Free Hanging (In-Line) | - | - | Wire Leads |
|
CT-0400-D20CURR SENSE XFMR 400:5 DONUT |
5 |
|
Datasheet | CT | Bulk | Active | - | Non-Invasive (Solid Core) | 400 A | - | - | - | 400:5 | - | - | Free Hanging (In-Line) | - | - | Wire Leads |
|
170SHT-501-ECURR SENSE XFMR CHAS MNT |
2 |
|
- |
CT | Bulk | Active | 50Hz ~ 400Hz | Non-Invasive (Solid Core) | - | - | - | - | 500:5 | - | - | Chassis Mount | 0.265" L x 0.265" W (6.73mm x 6.73mm) | 0.120" (3.05mm) | Stud |
|
CT-0100-D10CURR SENSE XFMR 100:5 DONUT |
1 |
|
Datasheet | CT | Bulk | Active | - | Non-Invasive (Solid Core) | 100 A | - | - | - | 100:5 | - | - | Free Hanging (In-Line) | - | - | Wire Leads |
|
CT-0100-F10CURR SENSE XFMR 100:5 FOOTED |
0 |
|
Datasheet | CT | Bulk | Active | - | Non-Invasive (Solid Core) | 100 A | - | - | - | 100:5 | - | - | - | - | - | Terminal Block |
|
CT-0400-F20CURR SENSE XFMR 400:5 FOOTED |
1 |
|
Datasheet | CT | Bulk | Active | - | Non-Invasive (Solid Core) | 400 A | - | - | - | 400:5 | - | - | - | - | - | Terminal Block |
